PVC geomembrane

›

‹

  • PVC geomembrane
  • PVC geomembrane
  • PVC geomembrane
  • PVC geomembrane

›

PVC geomembrane
Color: Black
Thickness: 0.5 mm - 2.0 mm
Material: Polyvinyl chloride (PVC) resin
Phone：+86 18053131421
Email：order@zonghuigeo.com
WhatsApp：+86 18053131421
Add：Room 3805 Metropolitan Vanke CenterLixia district Jinan City Shandong Province
Inquire Now

◉ PRODUCT SPECIFICATION

No.ItemValue
1Thickness of resin layer on top of intermediate tire base (mm) ≥0.4
2Tensile
properties		Maximum tensile strength (N/cm) ≥250
Tensile strength(Mpa) ≥-
Elongation at maximum tension (%)≥15
Elongation at break (%) ≥-
3Heat treatment dimensional change rate (%)≤0.5
4Low Temperature Bendability-25℃ no crack
5Impermeability0.3Mpa, impermeable for 2h
6Impact resistance0.5kg.m, no water seepage
7Resistant to static loads20kg No water seepage
8Seam peeling strength (N/cm) ≥3
9Right angle tear strength (N/cm) ≥-
10Trapezoidal tear strength (N) ≥250
11Water absorption (70℃, 168h) (%)After immersion ≤4
After cooling ≥-0.4
12Heat aging
(80 °C)		Timing672h
AspectNo blistering, cracking,
delamination, bonding or holes
Maximum Tension Retention (%) ≥85
Tensile strength retention (%) ≥-
Elongation retention at maximum tension (%) ≥80
Elongation at break retention (%) ≥-
Low Temperature Bendability-20℃ no crack
13Chemical
Resistant		AspectNo blistering, cracking, delamination,
bonding or holes
Maximum tensile
strength retention (%) ≥		85
Tensile
strength retention (%) ≥		-
Elongation retention
at maximum tension (%) ≥		80
Elongation at break retention (%) ≥-
Low Temperature Bendability-20℃ no crack
14Artificial climate
accelerates aging

Timing

1500hb
AspectNo blistering, cracking, delamination,
bonding or holes
Maximum tensile strength retention (%) ≥85
Tensile strength retention (%) ≥-
Elongation retention at maximum tension (%) ≥80
Elongation at break retention (%) ≥-
Low Temperature Bendability-20℃ no crack


详情_05

详情_11

详情_14

The above information is for reference only. For more information, please feel free to contact us. We will respond promptly, answer your questions patiently, and serve you wholeheartedly.
