Continuous filament spunbonded needle-punched nonwoven geotextile

Continuous filament spunbonded needle-punched nonwoven geotextile
Material:PP & PET
Type:Non-Woven Geotextiles
Model Number:100gsm-1500gsm
Application:Separation/filtration/drainage/reinforcement/protection/liquid barrier
Phone:+86 18053131421
Email:order@zonghuigeo.com
WhatsApp:+86 18053131421
Add:Room 3805 Metropolitan Vanke CenterLixia district Jinan City Shandong Province
Inquire Now

◉ PRODUCT SPECIFICATION

Filament spunbond nonwovens Geotextile Specifications(GB/T 17639-2008)


Item

Value

Specification

100

150

200

300

400

500

600

800

Thickness mm

0.8

1.2

1.6

2.2

2.8

3.4

4.2

5.5

Longitudinal and transverse rupture strength(KN/M)

4.5

7.5

10.0

15.0

20.0

25.0

30.0

40.0

Intensty corresponding to the standard vertical and horizontal elongation(%)

40~80

CBR bursting strength(KN)

0.8

1.6

1.9

2.9

3.9

5.3

6.4

7.9

Vertical and horizontal tear(KN)

0.14

0.21

0.28

0.42

0.56

0.70

0.82

1.10

Sieve size O(mm)

0.05~0.20

Vertical Pemeability Coefficient

K*(10-1~10-3)

K=1.0~9.9cm/s

Width Variation %

-0.5

Deviation of mass per unit area

-5

Continuous filament spunbonded needle-punched nonwoven geotextile


Continuous filament spunbonded needle-punched nonwoven geotextile


Shandong Zonghui Trading Co., Ltd. is one of China's leading geosynthetic material manufacturers. The company produces a range of environmentally friendly geosynthetics, including geomembranes, geotextiles, geogrids, 3D soil stabilization mats, geocells, geonets, geomembranes, PP/PE woven fabrics, weed control fabrics, waterproofing boards, GCL bentonite waterproofing blankets, 3D composite drainage nets, eco-bags, (storage) drainage boards, HDPE pipes, and more. Whether you are involved in environmental protection projects, infrastructure construction, civil engineering, or any other field requiring geosynthetic material solutions, Zonghui can provide support. Welcome to contact us and become our partner.

Continuous filament spunbonded needle-punched nonwoven geotextile

The above information is for reference only. For more information, please feel free to contact us. We will respond promptly, answer your questions patiently, and serve you wholeheartedly.
